Spare parts catalog for the 2-speed Puch Z50 engine, which was also installed in KTM mopeds.
The complete engine with the kickstart unit and the carburetor are shown in exploded drawings. Each individual component is provided with part number, spare part number and installation location.
Superb Austrian catalog from 1978 with 23 interesting pages.
Details
| Material | Paper |
| DIN format | A4 |
| Number of pages | 23 pcs |
| Language | German |
Suitable for the following models
| Puch | Z50 (X30 Sport) |
