Sachs engine & gearbox

Here you will find spare parts and tuning parts such as clutches, crankshafts, bearings, seals and oil seals, as well as cylinders, individual pistons or complete overhaul kits for the restoration of your Sachs 502, 50/2, 50/3, 50/4, 503, 504 or 505 engines with 1- or 2-speed automatic transmission and with 2-, 3- or 4-speed manual or foot-operated transmission. These legendary Fichtel & Sachs engines with manual or automatic gearstick were installed in Hercules, Rixe, Pony Junior, KTM and many other mopeds.

Albero motore Jasil (cuscinetto L17) | Sachs 50/3 & 50/4

For: Sachs

12137

Jasil crankshaft (L17 bearing) | Sachs 50/3 & 50/4

Manufacturer: Jasil · Cheek type: standard · Total length crankpin ignition side: 70.6 mm · Ø Bearing seat (clutch side): 17 mm · Ø Bearing seat (ignition side): 17 mm · Thread type: MF10x1 (fine pitch thread) · Number of gears: 3 pcs · Number of gears: 4 pcs · Area of application: Standard

EUR 157.50

Used

Coperchio della custodia piccolo Occ. | Sachs 50/2 (Tipo 1)

For: Sachs

12160

Housing cover small Occ. | Sachs 50/2 (Type 1)

Manufacturer: Sachs · Material: Aluminum · Surface: varnished · Color: silver · Pony OEM number: A1024 · Sachs OEM no.: 0211 069 206

EUR 39.30

Not in stock

swiing® revival gasket ignition cover | Sachs 503 AB, AC, ADV (A5671)

For: Sachs

12005

swiing® revival gasket ignition cover | Sachs 503 AB, AC, ADV (A5671)

Manufacturer: swiing® revival parts · Material: Sealing paper · Number of components: 1 pcs · Thickness: 0.4 mm · Number of fixing points: 4 pcs

EUR 6.65

For: Sachs

17749

GPO retaining plate clutch basket Sachs

Manufacturer: GPO · Area of application: Special tool · Material: Steel · Surface: galvanized (blue) · Number of components: 1 pcs · Total length: 135 mm · Width: 51 mm · Thickness: 4.6 mm · Ø inside: 40 mm

EUR 31.40

Pistone Meteor sovradimensionato di 39,2 mm | Sachs 50/2 & 503

For: Sachs

11671

Meteor piston 39.2 mm oversize | Sachs 50/2 & 503

Manufacturer: Meteor · Nominal diameter: 38 mm · Ø outside piston (A): 39.2 mm · Ø piston pin (B): 12 mm · Compression height (C): 28 mm · Curvature (D): 3 mm · Total piston height (E): 53 mm · Number of piston rings (F): 2 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Flank safety device (FS) · Piston ring height: 2 mm · Piston weight: 88 g · Pony OEM number: A2776 · Sachs OEM no.: 0286 377 014

EUR 56.20

Pistone Meteor 38 mm | Sachs 50/2, 503 (A2772)

For: Sachs

11667

Meteor piston 38 mm | Sachs 50/2, 503 (A2772)

Manufacturer: Meteor · Nominal diameter: 38 mm · Ø outside piston (A): 37.95 mm · Ø piston pin (B): 12 mm · Compression height (C): 28 mm · Curvature (D): 3 mm · Total piston height (E): 53 mm · Number of piston rings (F): 2 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Flank safety device (FS) · Piston ring height: 2 mm · Thick piston ring: 1.6 mm · Piston weight: 79 g · Pony OEM number: A2772 · Pony OEM number: A4358 · Sachs OEM no.: 0286 377 010 · Sachs OEM no.: 0286 378 005

EUR 56.20

swiing® revival gommino cavo accensione | Sachs 503 2AL/2BL/AAL, 535 (A4521)

For: Sachs

15220

swiing® revival rubber grommet ignition cable | Sachs 503 2AL/2BL/AAL, 535 (A4521)

Manufacturer: swiing® revival parts · Material: Rubber · Ø Cable bushing: 5.2 mm · Ø mounting hole: 8.5 mm · Ø outside: 10.5 mm · Ø Bundle: 10.5 mm · Waistband height: 3 mm · Color: black · Pony OEM number: A4520 · Pony OEM number: A4521 · Sachs OEM no.: 0960 135 000 · Sachs OEM no.: 0960 136 000

EUR 6.65

Pistone Meteor 37,99 mm tipo C | Sachs 504

For: Sachs

17198

Meteor piston 37.99 mm type C | Sachs 504

Manufacturer: Meteor · Nominal diameter: 38 mm · Ø outside piston (A): 37.99 mm · Ø piston pin (B): 12 mm · Compression height (C): 28 mm · Curvature (D): 3 mm · Total piston height (E): 53 mm · Number of piston rings (F): 2 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Flank safety device (FS) · Piston ring height: 2 mm · Tolerance group: C · Piston weight: 77 g

EUR 63.50

Pistone Meteor 40,0 mm sovradimensionato | Sachs 50/2 & 503

For: Sachs

17195

Meteor piston 40.0 mm oversize | Sachs 50/2 & 503

Manufacturer: Meteor · Nominal diameter: 40 mm · Ø outside piston (A): 39.95 mm · Ø piston pin (B): 12 mm · Compression height (C): 28 mm · Curvature (D): 3 mm · Total piston height (E): 53 mm · Number of piston rings (F): 2 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Flank safety device (FS) · Piston ring height: 2 mm · Piston weight: 94 g

EUR 67.40

swiing® revival gasket cylinder base 0.3 mm | Sachs 50, 50/3, 50/4 DE engines

For: Sachs

12001

swiing® revival gasket cylinder base 0.3 mm | Sachs 50, 50/3, 50/4 DE engines

Manufacturer: swiing® revival parts · Material: Oiled paper · Place of use: Cylinder base · Thickness: 0.5 mm · Hole pattern [mm]: 40.5 x 51

EUR 3.95

swiing® revival gasket cylinder head | Sachs 503 AB/AC/ADV

For: Sachs

12003

swiing® revival gasket cylinder head | Sachs 503 AB/AC/ADV

Manufacturer: swiing® revival parts · Place of use: Cylinder head · Reinforced: Yes · Nominal diameter: 38 mm

EUR 9.45

swiing® revival stud bolt M5 x 23 mm inlet (diaphragm) 10.9 | Sachs 50/2 (A3700)

For: Sachs

16088

swiing® revival stud bolt M5 x 23 mm inlet (diaphragm) 10.9 | Sachs 50/2 (A3700)

Manufacturer: swiing® revival parts · Material: Steel · Surface: galvanized (blue) · Area of application: Standard · Diameter: 4.9 mm · Thread type: M5x0.8 (standard thread) · Total length: 23 mm · Thread length: 6 mm · Thread length: 12 mm · Pony OEM number: A3700 · Sachs OEM no.: 0640 016 101 · Sachs OEM no.: 0640 016 102

EUR 2.05

Spacer washer 13/19/0.1 Pinion shaft / Kickstarter | Sachs

For: Sachs

15902

Spacer washer 13/19/0.1 Pinion shaft / Kickstarter | Sachs

Ø inside: 13 mm · Nominal diameter inside: 13 mm · Ø outside: 19 mm · Thickness: 0.1 mm · Manufacturer: Sachs · Material: Steel · Surface: blank / oiled

EUR 2.15

Oil seal NBR 24.8/31.4/4 A Brake shaft | Sachs 50

For: Sachs

17143

Oil seal NBR 24.8/31.4/4 A Brake shaft | Sachs 50

Place of use: Clutch cover · Temperature resistance (min.): -30 - 100 °C · Simmering type: A - With rubberized outer part / one sealing lip. · Ø inside: 24.8 mm · Ø outside: 31.4 mm · Width: 4 mm · Manufacturer: Sachs · Material: NBR · Surface: rubberized

EUR 6.55

Oil seal NBR 15/35/7 AS crankshaft | Sachs 504, 535 (A4214)

For: Sachs · Hercules

17044

Oil seal NBR 15/35/7 AS crankshaft | Sachs 504, 535 (A4214)

Place of use: Crankshaft · Temperature resistance (min.): -30 - 100 °C · Simmering type: AS - With rubberized outer casing / one sealing lip / one dust lip. · Ø inside: 15 mm · Ø outside: 35 mm · Width: 7 mm · Manufacturer: Sachs · Material: NBR · Surface: rubberized

EUR 10.00

Jasil crankshaft | Sachs 503 AB-CH / ABL CH (A2901 / A2902)

For: Sachs

17728

Jasil crankshaft | Sachs 503 AB-CH / ABL CH (A2901 / A2902)

Manufacturer: Jasil · Material: Steel · Cheek type: standard · Crankshaft stroke: 42 mm · Connecting rod length center-center: 84 mm · Total length of crankpin on clutch side: 101.15 mm · Total length crankpin ignition side: 64.1 mm · Ø crank webs: 85 mm · Ø piston pin (B): 12 mm · Ø Connecting rod eye: 15 mm · Ø Bearing seat (clutch side): 15 mm · Ø Bearing seat (ignition side): 15 mm · Thread type: MF10x1 (fine pitch thread) · Thread length: 11 mm · Dimension needle bearing: 12 / 15 x 12.8 mm (axe 12) · Wide crank webs: 30.3 mm · Length 1st paragraph: 19 mm · Length 2nd paragraph: 51 mm · Ø 1st step (on the coupling side): 15 mm · Ø 2nd shoulder (on the clutch side): 14 mm · Ø 3rd step (on the clutch side): 8 mm · Length of shoulder (ignition side): 34 mm · Weight: 875 g · Number of gears: 2 pcs · Area of application: Standard · Alternative version of the Pony OEM number: A2900 · Pony OEM number: A2901 · Pony OEM number: A2902 · Alternative version of the Sachs OEM number: 0288 115 002 · Alternative version of the Sachs OEM number: 0288 115 102

EUR 236.30

Gearbox cover gasket manual transmission | Sachs 50/2, 50/3, 50/4 A1827 0.4 mm (1A quality)

For: Sachs

11997

Gearbox cover gasket manual transmission | Sachs 50/2, 50/3, 50/4 A1827 0.4 mm (1A quality)

Material: Sealing paper · Color: sand-colored · Number of components: 1 pcs · Total length: 215 mm · Width: 130 mm · Thickness: 0.4 mm · Number of fixing points: 5 pcs · Pony OEM number: A1827 · Sachs OEM no.: 0250 087 100

EUR 4.30

For: Sachs

17448

Crankshaft Sachs 50/3 & 50/4

Cheek type: standard · Crankshaft stroke: 42 mm · Total length of crankpin on clutch side: 42.8 mm · Total length crankpin ignition side: 70.5 mm · Ø Bearing seat (clutch side): 17 mm · Ø Bearing seat (ignition side): 17 mm · Thread type: MF10x1 (fine pitch thread) · Number of gears: 3 pcs · Number of gears: 4 pcs · Area of application: Standard

EUR 168.80

Rubber washer under notched nail | Sachs 50/2, 503 AB/AC/ABL (A3890)

For: Sachs

15073

Rubber washer under notched nail | Sachs 50/2, 503 AB/AC/ABL (A3890)

Material: Rubber · Color: black · Ø inside: 3 mm · Height: 1.8 mm · Ø outside: 10 mm · Pony OEM number: A3890 · Sachs OEM no.: 0660 002 000

EUR 2.70

swiing® leva ingegnosa per decompressore | Sachs 503 (A1782)

For: Sachs

15083

swiing® ingenious lever for decompressor | Sachs 503 (A1782)

Manufacturer: swiing® ingenious parts · Color: silver · Alternative version of the Pony OEM number: A1782 · Alternative version of the Sachs OEM number: 0248 149 000

EUR 22.40

Paraolio NBR 15/30/7 B AS | Sachs 503, 50/2

For: Sachs

11986

Oil seal NBR 15/30/7 B AS | Sachs 503, 50/2

Temperature resistance (min.): -30 - 100 °C · Simmering type: B - With sheet metal outer casing / one sealing lip. · Ø inside: 15 mm · Ø outside: 30 mm · Width: 7 mm · Manufacturer: Sachs · Material: NBR · Pony OEM number: A1830 · Sachs OEM no.: 0250 090 000

EUR 6.10

Jasil crankshaft (axe 14 mm) | Sachs 50/5 & 50/6

For: Sachs

17450

Jasil crankshaft (axe 14 mm) | Sachs 50/5 & 50/6

Manufacturer: Jasil · Cheek type: Full cheeks · Crankshaft stroke: 44 mm · Total length of crankpin on clutch side: 72 mm · Total length crankpin ignition side: 72 mm · Ø piston pin (B): 14 mm · Ø Bearing seat (clutch side): 17 mm · Ø Bearing seat (ignition side): 17 mm · Thread type: MF10x1 (fine pitch thread) · Thread type: MF12x1.5 (fine pitch thread) · Number of gears: 5 pcs · Number of gears: 6 pcs · Area of application: Standard

EUR 168.80

For: Sachs

17716

Nut & spring washer clutch hub | Sachs

Nut type: Hexagon nut · Thread type: MF12x1 (fine pitch thread) · Drive: External hexagon · Width across flats SW: 17 mm

EUR 6.10

Coperchio dell'accensione (versione senza comando del tachimetro) | Sachs 50/2, 50/3, 50/4 (A1001)

For: Sachs

17113

Ignition cover (version without speedometer drive) | Sachs 50/2, 50/3, 50/4 (A1001)

Material: Aluminum · Number of fixing points: 2 pcs · Pony OEM number: A1001 · Sachs OEM no.: 0211 032 006

EUR 71.90

Spacer washer 12/18/0.1 drive wheel | Sachs 503

For: Sachs

17229

Spacer washer 12/18/0.1 drive wheel | Sachs 503

Ø inside: 12 mm · Nominal diameter inside: 12 mm · Ø outside: 18 mm · Thickness: 0.1 mm · Manufacturer: Sachs · Material: Steel · Surface: blank / oiled

EUR 2.15

Alloggiamento motore Cambio manuale a 3 marce | Sachs 50/3

For: Sachs

15487

Engine housing 3-speed manual transmission | Sachs 50/3

Material: Aluminum · Surface: varnished · Color: silver · Stock number: E15

EUR 337.60

Nos

Decompressore per karcoma M10x1,5 45° NOS

For: Sachs · Zündapp Belmondo

17512

Karcoma decompressor M10x1.5 45° NOS

Manufacturer: Karcoma · Material: Steel · Surface: galvanized (blue) · Angle: 45 ° · Thread type: M10x1.5 (standard thread) · Thread length: 9 mm · Total length: 64 mm · Width across flats SW: 14 mm · Area of application: Standard

EUR 30.30

For: Sachs

18490

Wedge for flywheel | Sachs 504, 508

Total length: 9.3 mm · Width: 2 mm · Height: 3.8 mm · Material: Steel · Sachs OEM no.: 0246 005 000

EUR 2.15

For: Sachs

17135

Kickstarter stop | Sachs 50/3, 50/4

Material: Metal

EUR 32.50

Spacer washer 12/18/0.3 drive wheel | Sachs 503

For: Sachs

17230

Spacer washer 12/18/0.3 drive wheel | Sachs 503

Ø inside: 12 mm · Nominal diameter inside: 12 mm · Ø outside: 18 mm · Thickness: 0.3 mm · Manufacturer: Sachs · Material: Steel · Surface: blank / oiled

EUR 2.15

Meccanismo di avviamento con ruota a cricchetto | Sachs

For: Sachs

17129

Ratchet wheel kickstart mechanism | Sachs

Material: Metal

EUR 67.40

For: Sachs

16919

ESJOT sprocket 13 | Sachs (50/3, 50/4)

Manufacturer: ESJOT · Material: Steel · Surface: raw · Chain pitch: 1/2" x 3/16" · Chain type: 415H · Number of teeth: 13 pcs · Recording type: Ø15 x SW12 · Cranking (offset): 10.5 mm

EUR 33.70

Spacer washer 13/19/0.5 Pinion shaft / Kickstarter | Sachs

For: Sachs

15906

Spacer washer 13/19/0.5 Pinion shaft / Kickstarter | Sachs

Ø inside: 13 mm · Nominal diameter inside: 13 mm · Ø outside: 19 mm · Thickness: 0.5 mm · Manufacturer: Sachs · Material: Steel · Surface: blank / oiled · Pony OEM number: A1533 · Sachs OEM no.: 0244 006 000

EUR 2.15

32 mm copper ring 30.6/37.8 flame tube | Sachs

For: Universal · Sachs

12136

32 mm copper ring 30.6/37.8 flame tube | Sachs

Ø inside: 30.6 mm · Ø outside: 37.8 mm · Material: Copper

EUR 5.50

Guarnizione albero NBR 12,96/31,5/3,5 Albero pignone | Sachs 50/2 (A1137)

For: Sachs

12127

Shaft seal NBR 12.96/31.5/3.5 Pinion shaft | Sachs 50/2 (A1137)

Place of use: Pinion shaft · Temperature resistance (min.): -30 - 100 °C · Ø inside: 12.96 mm · Ø outside: 31.5 mm · Width: 3.5 mm · Manufacturer: Sachs · Material: NBR · Pony OEM number: A1137 · Sachs OEM no.: 0230 014 100

EUR 9.55

Pistone Meteor 38,9 mm oversize | Sachs 50/2 & 503

For: Sachs

11670

Meteor piston 38.9 mm oversize | Sachs 50/2 & 503

Manufacturer: Meteor · Nominal diameter: 38 mm · Ø outside piston (A): 38.85 mm · Ø piston pin (B): 12 mm · Compression height (C): 28 mm · Curvature (D): 3 mm · Total piston height (E): 53 mm · Number of piston rings (F): 2 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Flank safety device (FS) · Piston ring height: 2 mm · Piston weight: 86 g · Pony OEM number: A2775 · Sachs OEM no.: 0286 377 013

EUR 56.20

GPO clutch plates (2 pcs.) | Sachs 50/2, 503 2AL/2BL (A3887)

For: Sachs

11726

GPO clutch plates (2 pcs.) | Sachs 50/2, 503 2AL/2BL (A3887)

Manufacturer: GPO · Material: Composite materials · Material: Steel · Recording type: Interlocking · Ø inside: 29.6 mm · Ø inside: 35.6 mm · Ø outside: 93 mm · Number of slats: 2 pcs · Thickness: 3.3 mm · Area of application: Standard · Pony OEM number: A3887 · Sachs OEM no.: 0659 010 006

EUR 19.00

For: Sachs

16974

Crankshaft Sachs 50/2 AML (A2733)

Cheek type: standard · Total length of crankpin on clutch side: 94.5 mm · Area of application: Standard · Pony OEM number: A2733 · Sachs OEM no.: 0286 346 000

EUR 173.30

Pistone Meteor 37,97 mm tipo A | Sachs 504

For: Sachs

17196

Meteor piston 37.97 mm type A | Sachs 504

Manufacturer: Meteor · Nominal diameter: 38 mm · Ø outside piston (A): 37.97 mm · Ø piston pin (B): 12 mm · Compression height (C): 28 mm · Curvature (D): 3 mm · Total piston height (E): 53 mm · Number of piston rings (F): 2 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Flank safety device (FS) · Piston ring height: 2 mm · Piston weight: 78 g

EUR 63.50

For: Sachs

17066

Ring gear 50/3, 50/4

Ø inside: 29 mm · Nominal diameter inside: 29 mm · Ø outside: 32 mm · Total length: 7 mm

EUR 10.00

Countershaft with 15 teeth fixed gear | Sachs 50/3

For: Sachs

17058

Countershaft with 15 teeth fixed gear | Sachs 50/3

Number of teeth: 9 pcs · Number of teeth: 11 pcs · Number of teeth: 15 pcs · Toothing type: straight toothed · Total length: 96.6 mm

EUR 120.40

Disk 15.7/27/3 | Sachs 50/3, 50/4 Kickstarter models

For: Sachs

17071

Disk 15.7/27/3 | Sachs 50/3, 50/4 Kickstarter models

Ø inside: 15.7 mm · Nominal diameter inside: 16 mm · Ø outside: 27 mm · Thickness: 3 mm · Material: Steel · Surface: blank / oiled · Sachs OEM no.: A1598 · Sachs OEM no.: 0244 110 100

EUR 7.65

Spacer washer 13/19/0.15 Pinion shaft / Kickstarter | Sachs

For: Sachs

15903

Spacer washer 13/19/0.15 Pinion shaft / Kickstarter | Sachs

Ø inside: 13 mm · Nominal diameter inside: 13 mm · Ø outside: 19 mm · Thickness: 0.15 mm · Manufacturer: Sachs · Material: Steel · Surface: blank / oiled · Pony OEM number: A1540 · Sachs OEM no.: 0244 006 007

EUR 2.15

For: Sachs

17454

Large idler wheel 31 teeth | Sachs 50/4

Material: Steel · Surface: Hardened · Toothing type: straight toothed · Number of teeth: 31 pcs

EUR 41.60

Not in stock

Crankshaft | Sachs 505, 535 A1, 535 AV (A4477)

For: Sachs · Hercules

17449

Crankshaft | Sachs 505, 535 A1, 535 AV (A4477)

Material: Steel · Crankshaft stroke: 44 mm · Connecting rod length center-center: 85 mm · Total length of crankpin on clutch side: 77.5 mm · Total length crankpin ignition side: 73.5 mm · Ø crank webs: 79.9 mm · Ø piston pin (B): 12 mm · Ø Connecting rod eye: 15 mm · Ø Bearing seat (clutch side): 15 mm · Ø Bearing seat (ignition side): 15 mm · Thread type: MF10x1 (fine pitch thread) · Thread length: 12 mm · Dimension needle bearing: 12 / 15 x 14.2 mm (axe 12) · Wide crank webs: 34.3 mm · Length 1st paragraph: 18 mm · Length 2nd paragraph: 44 mm · Ø 1st step (on the coupling side): 15 mm · Ø 2nd shoulder (on the clutch side): 11.6 mm · Length of shoulder (ignition side): 42.5 mm · Weight: 956 g · Number of gears: 1 pcs · Number of gears: 2 pcs · Area of application: Standard · Pony OEM number: A4477

EUR 191.30

Pistone 39 mm | Sachs 50/3, 50/4 raffreddato a ventola

For: Sachs

17328

Piston 39 mm | Sachs 50/3, 50/4 fan-cooled

Nominal diameter: 39 mm · Ø outside piston (A): 38.96 mm · Ø piston pin (B): 12 mm · Compression height (C): 27.75 mm · Curvature (D): 3.35 mm · Total piston height (E): 53.1 mm · Number of piston rings (F): 2 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Flank safety device (FS) · Piston ring height: 2 mm · Piston weight: 83 g

EUR 49.40

For: Sachs

17456

Spacer bushing gearbox Sachs 50/4

Ø inside: 16 mm · Nominal diameter inside: 16 mm · Ø outside: 20 mm · Total length: 16 mm

EUR 10.00

Cuscinetto reggispinta frizione di avviamento | Sachs 502 AL, AML / 503 AAL, AC, ADV (A1175)

For: Sachs

15080

Thrust bearing starter clutch | Sachs 502 AL, AML / 503 AAL, AC, ADV (A1175)

Bearing type: Ball ring · Stock number: L51106 · Bearing cage: "-" Sheet steel cage ball-guided · Pony OEM number: A1175 · Sachs OEM no.: 0232 136 000

EUR 10.70
