15 mm intake manifold Dell'Orto SHA

Dell'Orto reduction rifle SHA (21/19-17.7 mm)

Manufacturer: Dell'Orto · Material: Plastic · Component group Carburetor: Adjusting screws, float, etc. · Carburetor type: SHA · Ø inside: 19 mm · Color: white · Ø Passage: 17.7 mm · Ø outside: 21 mm · Total length: 14 mm

GPO 15 mm carburetor tuning | Puch

Manufacturer: GPO · Material: Aluminum · Camouflaged: No · Component group Carburetor: Carburetor complete · Width: 50 mm · Carburetor type: SRE · Nominal diameter: 15 mm · Total length: 66 mm · Ø Internal connection: 20 mm · Height: 95 mm · Ø Inside entrance: 15 mm · Mounting type: Plug connection clamped · Ø Output inside: 15 mm · Ø Air filter connection: 20 mm · Area of application: Tuning · Ø fuel hose connection: 6 mm · Mixed oil connection: No · Vacuum connection: No · Choke control: Hand choke · Nozzle thread: M3.5x0.6 (standard thread) · Nozzle block: 2.17 · Nozzle size: 62 · Clamping screw torque (max.): 4 N/m

Airsal 44 mm cylinder kit 65 ccm camouflaged | Puch

Manufacturer: Airsal · Material: Aluminum · Camouflaged: Yes · Surface: sandblasted · Displacement: 65 ccm · Crankshaft stroke: 43 mm · Nominal diameter: 44 mm · Ø cylinder neck: 48 mm · Ø outlet inside: 25 mm · Inlet window: 24 / 20 x 15 · Thread inlet: M6x1 (standard thread) · Number of fixing points: 4 pcs · Area of application: Tuning · Ø piston pin (B): 12 mm · Hole pattern [mm]: 44 x 44 · Outlet type: straight · Hole spacing outlet: 42 mm · Thread outlet: M6x1 (standard thread) · Decompressor: Yes · Hole spacing inlet: 38 mm

Dell'Orto 16/16 SHA carburetor hand choke

Nominal diameter: 16 mm · Manufacturer: Dell'Orto · Material: Aluminum · Camouflaged: No · Component group Carburetor: Carburetor complete · Color: black · Carburetor type: SHA · Width: 72 mm · Choke control: Hand choke · Height: 111 mm · Total length: 82 mm · Area of application: Tuning · Ø fuel hose connection: 5.1 mm · Ø fuel hose connection: 6 mm · Ø Internal connection: 19 mm · Ø without reducing sleeve: 21 mm · Ø Inside entrance: 16 mm · Mounting type: Plug connection clamped · Ø Output inside: 16 mm · Ø Air filter connection: 56 mm · Ø Air filter connection: 58.5 mm · Mixed oil connection: No · Vacuum connection: No · Nozzle thread: M5x0.8 (standard thread) · Nozzle size: 82

Motorex Automatic Motor Oil (ATF) 450 ml

Temperature resistance (min.): -45 - 200 °C · Manufacturer: Motorex · Contents [ml]: 450 ml · Gearbox type: Automatic machine · Area of application: Gearbox lubrication with clutch · Sachs OEM no.: 0263 014 002 · Pony OEM number: A2080

Exhaust cigar 28 mm chrome | Puch Maxi S, N / X30 NS, NL

Manufacturer: Made in Portugal · Material: Steel · Surface: chrome-plated · Color: Chrome · Total length: 920 mm · Ø Internal connection: 28 mm · Ø outside: 70 mm · Mounting type: Stud bolts & nuts · Mounting type: Welded lug · Number of fixing points: 1 pcs · Ø Flame tube outside: 28 mm · Exhaust type: Cigar · Flame tube attachment: Flange

Gas cable Ø 1.2 mm x 165 cm (nipple ball) Dell'Orto

Ø nipple: 3.5 mm · Manufacturer: Made in Germany · Number of components: 1 pcs · Material: Steel · Surface: galvanized (blue) · Ø Stranded wire: 1.2 mm · Cable length: 1650 mm · Nipple shape: Ball · Area of application: Standard

swiing nozzle set M5 (70 - 92) Dell'Orto SHA, PHBG

Manufacturer: swiing · Material: Brass · Component group Carburetor: Spraying · Quantity: 10 pcs · Carburetor type: PHBG · Carburetor type: SHA · Carburetor type: SHA (Piaggio) · Nozzle type: Main nozzle · Total length: 8 mm · Drive: Slot · Nozzle thread: M5x0.8 (standard thread) · Nozzle size: 70 · Nozzle size: 72 · Nozzle size: 75 · Nozzle size: 78 · Nozzle size: 80 · Nozzle size: 82 · Nozzle size: 85 · Nozzle size: 88 · Nozzle size: 90 · Nozzle size: 92

Airsal intake gasket 0.45 mm racing kit | Puch

Manufacturer: Airsal · Place of use: Admission · Material: Sealing paper · Reinforced: No · Ø screw holder: 6.7 mm · Area of application: Standard · Thickness: 0.4 mm · Hole spacing inlet: 38 mm

Dell'Orto reduction rifle SHA (21/19-17.7 mm)

Manufacturer: Dell'Orto · Material: Plastic · Component group Carburetor: Adjusting screws, float, etc. · Carburetor type: SHA · Ø inside: 19 mm · Color: white · Ø Passage: 17.7 mm · Ø outside: 21 mm · Total length: 14 mm

Dell'Orto carburetor set SHA 16/16 | Puch Maxi S, N

Manufacturer: Dell'Orto · Component group Carburetor: Carburetor complete · Carburetor type: SHA · Nominal diameter: 16 mm · Mounting type: Flange · Mounting type: Plug connection clamped · Hole spacing inlet: 38 mm · Ø fuel hose connection: 6 mm · Choke control: Hand choke · Area of application: Tuning · Nozzle thread: M5x0.8 (standard thread)
